| BRAND： | CRYSTAL CODE | CODE： | CCBHT502 |
| INDUSTRIAL： | ELECTRONICS | SIZE： | CUSTOMIZED |
| COLOUR： | CMYK | MATERIAL： | PET,PP,PVC |
I．Product Introduction
This product is a high-frequency electronic labels that use polyphenylenesulfide (PPS) material package, which is designed for a special occasion suchas dry-clean, so called laundry label. Polyphenylene sulfide (PPS) is astructurally stable crystalline resin plastic of high rigidity, which has hightemperature, non-toxic, flame resistance, chemical resistance, good insulationperformance, etc. Available in rigid, durable mechanical products; requiringheat, the fire electrical products; also available in terms of requirements forchemical devices of corrosion resistance. Especially at high temperatures, highhumidity and high frequency, it stillhas excellent electrical properties. PPS plastic shell, after using electronictags encapsulated ultrasonic sealing, has high temperature, flame resistance,chemical resistance, high rigidity wear-resistant, waterproof and many otheradvantages, can be used in high temperature, high humidity, wear and corrosionresistance in harsh environmental applications, such as: laundry, car enginerepair identification, chemical raw materials and many electronic tags to trackapplications.
Features:
I. operating distance:0~150px(dependenton the geometry of the antenna and reader power)
II. OperatingFrequency: 13.56 MHz (industrial safety, worldwide license free use)
III. Standard protocol: ISO15693
IV. True anti-collision: Allows multiple tagssimultaneously read
V. More than 10 years of data retention
VI. Erase cycle more than thousandsof times
VII. Unique identifier (serialnumber) for each chip has not changed, to ensure the uniqueness of each label
II.Technicalparameters
operation code | HT502 |
Operating Frequency | 13.56MHz |
Communicating protocol | ISO 15693 |
Chip Type | NXP ICODE II SLIX |
Reading distance | 0~150px |
Reading time | 20~30ms |
Working temperature | -20℃~90℃ |
Storage temperature | 25 ℃ or +120 ℃ / 1000 hours;+160℃/35hours;+220℃/30second |
Chemical properties | Flooding test: 20 ℃, 24 hours, and the depth of 2m (does not affect the read and write performance). Chemical tests: bleach / caustic soda (20 ℃ / 10 hours does not affect the appearance and read and write performance) |
Mechanical properties | Balanced Pressure: 20Mpa / 5 min (high rigidity, the appearance of no cracked or broken). Axial pressure: 1Kpa / 10 seconds (the appearance of no cracked or broken). Vibration test: The vibration frequency of 34Hz, vibration strength 6mm / 2 hours (the appearance of no cracked or broken) |
Endurance | >100,000times |
Data retention | >10years |
Dimensions | D22 × 2.5mm (with two holes), D30 × 4.8mm (hole with 8 characters) or customized |
Packaging Materials | PPS |
Weight | 7g |
Installation | Stapling or engaging |
Feature: | Water-proof, High temperature, flame resistance, chemical resistance |
Applications: | Dry cleaning management Professional suite laundry management, car engine repair identification |
Price terms: | We can provide FOB /EXW/CIF price. |
Payment term: pay by T/T or Western Union. 50% deposit of the total payment before bulk production. (We will take photos or show you the goods by video after finish the goods to make sure quality and quantity are not an issue to stop our business relationship.) |
Delivery time: | within 10-15 days after the receipt of 50% deposit of the total payment. |
Delivery way: | By express(DHL, Fedex, UPS, TNT and EMS) ,by sea or air |
Packaging:(Standard Size) | White Box: 10 rolls /BOX, Our Carton: 25Boxes/CTN.Or on demand. |
Sample: | Free sample based on your order quantity |
Standard size card weights (only for reference) | 10 rolls(1 box) 20 KG |
