Crystal Code Packaging Technology (Shang hai) Co. LtdAbout UsRoom 1503-1505, 100 Jinyu Road, Jinqiao Development Zone, Pudong New District, ShanghaiCrystal Code Packaging Technology (Shanghai) Co.,Ltd. (hereinafter Crystal Code) establish in 2011, Subordinate to Crystal Code Package Group. We are a high technology enterprises which is focus on R&D and production for special sticker labels and packaging materials. Main products including package materials for steel, chemical, anti-fake, food and drinks industry. Especially we have abundant experience in high/low temperature resistance labels supply ,we have our own technology and advanced products and have provided entire professional solution to many clients worldwide. Crystal Code Packaging Technology (Shang hai) Co. LtdAbout UsRoom 1503-1505, 100 Jinyu Road, Jinqiao Development Zone, Pudong New District, ShanghaiCrystal Code Packaging Technology (Shanghai) Co.,Ltd. (hereinafter Crystal Code) establish in 2011, Subordinate to Crystal Code Package Group. We are a high technology enterprises which is focus on R&D and production for special sticker labels and packaging materials. Main products including package materials for steel, chemical, anti-fake, food and drinks industry. Especially we have abundant experience in high/low temperature resistance labels supply ,we have our own technology and advanced products and have provided entire professional solution to many clients worldwide. Crystal Code Pa
I．Product Introduction ★Dataand power supply: non-contact transmission (no battery-powered) ★Operating distance: 1~150px (dependenton the geometry of the antenna and reader power) ★Operating Frequency: 13.56 MHz(industrial safety, worldwide license free use)
★Fast data transfer: Achieve106Kbit / s ★High integrity of data: 16 bitCRC checksum ★Trueanti-collision: Allows multiple tags simultaneously read ★Supportdata encryption, each sector achieve alone password management ★More than 10years of data retention ★Erase cycle morethan thousands of times ★Unique identifier(serial number) for each chip has not changed, to ensure the uniqueness of eachlabel
II.Technicalparameters
operation code
CCBHT301
Operating Frequency
13.56MHz
Communicating protocol
ISO 14443A
Chip Type
FM11RF08
Antenna Type
Etched aluminum antenna
Reading distance
0 ~ 150px
Reading time
20~30ms
Working temperature
-20℃~85℃
Endurance
>100,000times
Data retention
>10years
Dimensions
86×54×0.8mm or customized
Packaging Materials
Coated stickers add to cattle leather sole paper or Glassine
Payment term: pay by T/T or Western Union. 50% deposit of the total payment before bulk production. (We will take photos or show you the goods by video after finish the goods to make sure quality and quantity are not an issue to stop our business relationship.)
Delivery time:
within 10-15 days after the receipt of 50% deposit of the total payment.
Delivery way:
By express(DHL, Fedex, UPS, TNT and EMS) ,by sea or air
Packaging:(Standard Size)
White Box: 10 rolls /BOX, Our Carton: 25Boxes/CTN. Or on demand.
