RFID CARD2

Model NO.: RFID CARD2
Delivery: FOB

Quantity:

Product Description

BRAND：	CRYSTAL CODE	CODE：	CCBUT102
INDUSTRIAL：	ELECTRONICS	SIZE：	CUSTOMIZED
COLOUR：	CMYK	MATERIAL：	PET,PP,PVC

I．Product Introduction
UHF（Ultra High Frequency） cassette label is a card-typeelectronic label that use of PVC laminated, which package of inside to etchedaluminum antenna base UHF Alien 9662 Inlay, compact and lightweight, with acertain resistance temperature resistance, waterproof, and certain mechanicalstrength, has a protective effect for chip, and cheaply. suitable for personnelmanagement, pallet management, production process management.
The process of this label is maturityand stability, suitable for high-volume automated production, cheaply, which isa cost-effective label that can recyclable .

II. Technicalparameters

operation code	UT102
Operating Frequency	860~960MHz
Communicating protocol	ISO 18000-6C, EPC Gen2
Chip Type	Alien Higgs-3
EPC	96bits, can expend to 480bits
User Memory	512bits
TID reserved area	64bits
reserved area	32bits kill password and 32bits access password
Reading distance	0 ~ 375px (dependent on the reader power)
Reading time	0~10ms
Working temperature	-20℃~85℃
Storage temperature	-20℃ ~ 85℃
Package	Melt laminated with sheet
Endurance	>100,000times
Data retention	>10years
Dimensions	86540.8mm
Packaging Materials	PVC
weight	7g
Installation	Hanging, screws or paste
Feature:	Water-proof, Temperature resistance
Applications:	personnel management, Pallet Management, Production Process Management
Price terms:	We can provide FOB /EXW/CIF price.
Price terms:	Payment term: pay by T/T or Western Union. 50% deposit of the total payment before bulk production. (We will take photos or show you the goods by video after finish the goods to make sure quality and quantity are not an issue to stop our business relationship.)
Delivery time:	within 10-15 days after the receipt of 50% deposit of the total payment.
Delivery way:	By express(DHL, Fedex, UPS, TNT and EMS) ,by sea or air
Packaging:(Standard Size)	White Box: 10 rolls /BOX, Our Carton: 25Boxes/CTN.Or on demand.
Sample:	Free sample based on your order quantity
Standard size card weights (only for reference)	10 rolls(1 box) 20 KG
